b-one Alnico Ceramic Guitar Humbuckers – B1-ACE-H

b-one Alnico Ceramic Guitar Humbuckers – B1-ACE-H

Hot vintage tone from a mixed magnetic circuit diverse-mount humbucker

List Price:

$180.00

 how to buy

SKU: b-one ACE-H Category:
SKU: b-one ACE-H Category:

The expanded tonal range and rich harmonics of our ACE pickups are created by combining alnico V blades and ceramic bar magnets for the best of both worlds, producing the hot tone you want from an alnico pickup, balanced with the clarity you expect from ceramic. The string-to-string output is balanced by internal compensation and field shaping. The blade design ensures your tone won’t fade from even the most aggressive bends.
b-one ACE Humbuckers are true pro-level pickups, so of course they are fully shielded against noise from stage lighting and studio equipment. They are sweat-proof and won’t make horrible noises when you touch them like many standard bobbin-style humbuckers. They are wired with shielded 4-conductor cable for coil splitting and series or parallel humbucker wiring.
Their Hot Vintage tone is great for Rock, Progressive, Funk, and Heavy Blues.
B1-ACE Humbuckers are black and come in balanced versions for neck (rhythm) and bridge (treble). Standard humbucker mounting screws are required (#3-48 x 1” recommended). Screws and other mounting hardware are not included – be sure to order what you need for your particular guitar.

Ordering Details

Model Description UPC Price
B1-ACE-H-70-BK ACE Guitar Pickup, 6 string, Humbucker, AlNiCo-Ceramic, Neck, B1 Collection, Black 682384507117 $180
B1-ACE-H-75-BK ACE Guitar Pickup, 6 string, Humbucker, AlNiCo-Ceramic, Bridge, B1 Collection, Black 682384507124 $180

Ordering Details

Model UPC Price
B1-ACE-H-70-BK 682384507117 $180
ACE Guitar Pickup, 6 string, Humbucker, AlNiCo-Ceramic, Neck, B1 Collection, Black
B1-ACE-H-75-BK 682384507124 $180
ACE Guitar Pickup, 6 string, Humbucker, AlNiCo-Ceramic, Bridge, B1 Collection, Black

b-one ACE-H Technical Details

Coil Structure:
Dual Parallel Humbucking
Cable Type:
4-Conductor Cable with shield and bare drain
Magnetic Circuit:
Alnico V blade magnets, carbon steel, brass, and copper reinforced and stabilized by ceramic (ferrite) magnets projected for focused aperture
Neck coil South and Bridge coil North

ACE-H-70 - Neck

  • DC Resistance: ~7.8KΩ each coil
  • Resonant Frequency: ~3.5KHz
  • Sensing Width: 2.01" [51mm] Max

ACE-H-75 - Bridge

  • DC Resistance: ~8.7KΩ each coil
  • Resonant Frequency: ~2.9KHz
  • Sensing Width: 2.01" [51mm] Max

Shape Details

B1-Humbucker

  • 2.75" [69.9mm] Long,
    1.52" [38.6mm] Wide,
    0.7-0.8" [17.8-20.3mm] Thick + 0.15" [3.8mm] Cable
  • Brass bracket with 3-48 tapped holes - Screws not provided
